Command Class Reference

Command base class from which all other commands are derived Derived classes must provide a unique constructor, destructor, and optionally provide a 'create_text' routine if the command has a text equivalent which should be echoed to a log file. More...

#include <Command.h>

Inheritance diagram for Command:

List of all members.

Public Types
enum	Cmdtype {   ROTMAT, ROTATE, TRANSLATE, SCALE,   ROCKON, ROCKOFF, STOPROT, ANIM_DIRECTION,   ANIM_JUMP, ANIM_SKIP, ANIM_STYLE, ANIM_SPEED,   ANIM_READ, ANIM_WRITE, ANIM_DELETE, ANIM_DUP,   ANIM_NEW_FRAME, ANIM_NEW_NUM_FRAMES, ATOMSEL_ADDMACRO, ATOMSEL_DELMACRO,   COLOR_NAME, COLOR_CHANGE, COLOR_SCALE_METHOD, COLOR_SCALE_SETTINGS,   COLOR_SCALE_COLORS, COLOR_ADD_ITEM, DISP_BACKGROUNDGRADIENT, DISP_RESETVIEW,   DISP_STEREO, DISP_STEREOSWAP, DISP_CACHEMODE, DISP_RENDERMODE,   DISP_PROJ, DISP_EYESEP, DISP_FOCALLEN, DISP_LIGHT_ON,   DISP_LIGHT_HL, DISP_LIGHT_ROT, DISP_LIGHT_MOVE, DISP_FPS,   DISP_CLIP, DISP_DEPTHCUE, DISP_CULLING, DISP_ANTIALIAS,   CMD_AXES, CMD_STAGE, DISP_SCRHEIGHT, DISP_SCRDIST,   DISP_CUESTART, DISP_CUEEND, DISP_CUEDENSITY, DISP_CUEMODE,   DISP_SHADOW, DISP_AO, DISP_AO_AMBIENT, DISP_AO_DIRECT,   IMD_ATTACH, IMD_SIM, IMD_RATE, IMD_COPYUNITCELL,   INTERP_EVENT, LABEL_ADD, LABEL_ADDSPRING, LABEL_SHOW,   LABEL_DELETE, LABEL_TEXTSIZE, LABEL_TEXTTHICKNESS, LABEL_TEXTOFFSET,   LABEL_TEXTFORMAT, MATERIAL_ADD, MATERIAL_RENAME, MATERIAL_CHANGE,   MATERIAL_DELETE, MATERIAL_DEFAULT, MENU_SHOW, MENU_TK_ADD,   MENU_TK_REMOVE, MOL_NEW, MOL_DEL, MOL_ACTIVE,   MOL_FIX, MOL_ON, MOL_TOP, MOL_SELECT,   MOL_REP, MOL_COLOR, MOL_ADDREP, MOL_DELREP,   MOL_MODREPITEM, MOL_MODREP, MOL_MATERIAL, MOL_CANCEL,   MOL_REANALYZE, MOL_BONDRECALC, MOL_SSRECALC, MOL_REPSELUPDATE,   MOL_REPCOLORUPDATE, MOL_DRAWFRAMES, MOL_SHOWPERIODIC, MOL_NUMPERIODIC,   MOL_SCALEMINMAX, MOL_SMOOTHREP, MOL_VOLUME, MOL_RENAME,   MOL_SHOWREP, MOUSE_MODE, PICK_EVENT, PLUGIN_UPDATE,   RENDER, RENDER_OPTION, MOBILE_MODE, SPACEBALL_MODE,   TOOL_CREATE, TOOL_CHANGE, TOOL_DELETE, TOOL_SCALE,   TOOL_SCALE_FORCE, TOOL_SCALE_SPRING, TOOL_OFFSET, TOOL_REP,   TOOL_ADD_DEVICE, TOOL_DELETE_DEVICE, TOOL_CALLBACK, TOTAL }
Public Methods
	Command (Cmdtype newtype)
	constructor ... command type, max length of text command, UI id constructor for derived class should print text rep of this command to the stream 'cmdText'. More...
virtual	~Command ()
	destructor; free string spaced used for text rep of this command. More...
int	has_text (Inform *str)
	if a Tcl text equivalent is available, write it into the given stream return whether this command has a text equivalent. More...
Cmdtype	gettype ()
	return unique ID code of this command. More...
Protected Methods
virtual void	create_text ()
	virtual function which is called when a text version of the command must be created to be printed to the console or a log file. More...
Protected Attributes
Inform *	cmdText
	stream-based object to format text. More...

---

Detailed Description

Command base class from which all other commands are derived Derived classes must provide a unique constructor, destructor, and optionally provide a 'create_text' routine if the command has a text equivalent which should be echoed to a log file.

Definition at line 45 of file Command.h.

---

Member Enumeration Documentation

enum Command::Cmdtype

Enumeration values: ROTMAT  ROTATE  TRANSLATE  SCALE  ROCKON  ROCKOFF  STOPROT  ANIM_DIRECTION  ANIM_JUMP  ANIM_SKIP  ANIM_STYLE  ANIM_SPEED  ANIM_READ  ANIM_WRITE  ANIM_DELETE  ANIM_DUP  ANIM_NEW_FRAME  ANIM_NEW_NUM_FRAMES  ATOMSEL_ADDMACRO  ATOMSEL_DELMACRO  COLOR_NAME  COLOR_CHANGE  COLOR_SCALE_METHOD  COLOR_SCALE_SETTINGS  COLOR_SCALE_COLORS  COLOR_ADD_ITEM  DISP_BACKGROUNDGRADIENT  DISP_RESETVIEW  DISP_STEREO  DISP_STEREOSWAP  DISP_CACHEMODE  DISP_RENDERMODE  DISP_PROJ  DISP_EYESEP  DISP_FOCALLEN  DISP_LIGHT_ON  DISP_LIGHT_HL  DISP_LIGHT_ROT  DISP_LIGHT_MOVE  DISP_FPS  DISP_CLIP  DISP_DEPTHCUE  DISP_CULLING  DISP_ANTIALIAS  CMD_AXES  CMD_STAGE  DISP_SCRHEIGHT  DISP_SCRDIST  DISP_CUESTART  DISP_CUEEND  DISP_CUEDENSITY  DISP_CUEMODE  DISP_SHADOW  DISP_AO  DISP_AO_AMBIENT  DISP_AO_DIRECT  IMD_ATTACH  IMD_SIM  IMD_RATE  IMD_COPYUNITCELL  INTERP_EVENT  LABEL_ADD  LABEL_ADDSPRING  LABEL_SHOW  LABEL_DELETE  LABEL_TEXTSIZE  LABEL_TEXTTHICKNESS  LABEL_TEXTOFFSET  LABEL_TEXTFORMAT  MATERIAL_ADD  MATERIAL_RENAME  MATERIAL_CHANGE  MATERIAL_DELETE  MATERIAL_DEFAULT  MENU_SHOW  MENU_TK_ADD  MENU_TK_REMOVE  MOL_NEW  MOL_DEL  MOL_ACTIVE  MOL_FIX  MOL_ON  MOL_TOP  MOL_SELECT  MOL_REP  MOL_COLOR  MOL_ADDREP  MOL_DELREP  MOL_MODREPITEM  MOL_MODREP  MOL_MATERIAL  MOL_CANCEL  MOL_REANALYZE  MOL_BONDRECALC  MOL_SSRECALC  MOL_REPSELUPDATE  MOL_REPCOLORUPDATE  MOL_DRAWFRAMES  MOL_SHOWPERIODIC  MOL_NUMPERIODIC  MOL_SCALEMINMAX  MOL_SMOOTHREP  MOL_VOLUME  MOL_RENAME  MOL_SHOWREP  MOUSE_MODE  PICK_EVENT  PLUGIN_UPDATE  RENDER  RENDER_OPTION  MOBILE_MODE  SPACEBALL_MODE  TOOL_CREATE  TOOL_CHANGE  TOOL_DELETE  TOOL_SCALE  TOOL_SCALE_FORCE  TOOL_SCALE_SPRING  TOOL_OFFSET  TOOL_REP  TOOL_ADD_DEVICE  TOOL_DELETE_DEVICE  TOOL_CALLBACK  TOTAL  Definition at line 50 of file Command.h. Referenced by Command, gettype, and CommandQueue::runcommand.

---

Constructor & Destructor Documentation

Command::Command (  Cmdtype    newtype )  [inline]

constructor ... command type, max length of text command, UI id constructor for derived class should print text rep of this command to the stream 'cmdText'. Definition at line 115 of file Command.h. References Cmdtype.

virtual Command::~Command (    )  [inline, virtual]

destructor; free string spaced used for text rep of this command. Definition at line 119 of file Command.h.

---

Member Function Documentation

virtual void Command::create_text (  void    )  [inline, protected, virtual]

virtual function which is called when a text version of the command must be created to be printed to the console or a log file. Reimplemented in CmdAnimDir. Definition at line 107 of file Command.h. Referenced by has_text.

Cmdtype Command::gettype (    )  [inline]

return unique ID code of this command. Definition at line 130 of file Command.h. References Cmdtype. Referenced by CommandQueue::runcommand.

int Command::has_text (  Inform *    str )  [inline]

if a Tcl text equivalent is available, write it into the given stream return whether this command has a text equivalent. Definition at line 123 of file Command.h. References create_text. Referenced by VMDCollab::act_on_command, and UIText::act_on_command.

---

Member Data Documentation

Inform* Command::cmdText [protected]

stream-based object to format text. Definition at line 103 of file Command.h. Referenced by CmdToolCallback::create_text, CmdToolRep::create_text, CmdToolDeleteDevice::create_text, CmdToolAddDevice::create_text, CmdToolOffset::create_text, CmdToolScaleSpring::create_text, CmdToolScaleForce::create_text, CmdToolScale::create_text, CmdToolDelete::create_text, CmdToolChange::create_text, CmdToolCreate::create_text, CmdRockOff::create_text, CmdRockOn::create_text, CmdScale::create_text, CmdTranslate::create_text, CmdRotate::create_text, CmdRotMat::create_text, CmdRender::create_text, CmdPluginUpdate::create_text, CmdMolShowRep::create_text, CmdMolSmoothRep::create_text, CmdMolDrawFrames::create_text, CmdMolScaleMinmax::create_text, CmdMolNumPeriodic::create_text, CmdMolShowPeriodic::create_text, CmdMolRename::create_text, CmdMolSSRecalc::create_text, CmdMolBondsRecalc::create_text, CmdMolReanalyze::create_text, CmdMolDeleteRep::create_text, CmdMolRepColorUpdate::create_text, CmdMolRepSelUpdate::create_text, CmdMolChangeRepItem::create_text, CmdMolChangeRep::create_text, CmdMolAddRep::create_text, CmdMolMaterial::create_text, CmdMolColor::create_text, CmdMolRep::create_text, CmdMolSelect::create_text, CmdMolTop::create_text, CmdMolOn::create_text, CmdMolFix::create_text, CmdMolActive::create_text, CmdMolCancel::create_text, CmdMolDelete::create_text, CmdMolLoad::create_text, CmdMenuShow::create_text, CmdMaterialDefault::create_text, CmdMaterialDelete::create_text, CmdMaterialChange::create_text, CmdMaterialRename::create_text, CmdMaterialAdd::create_text, CmdLabelTextFormat::create_text, CmdLabelTextOffset::create_text, CmdLabelTextThickness::create_text, CmdLabelTextSize::create_text, CmdLabelDelete::create_text, CmdLabelShow::create_text, CmdLabelAdd::create_text, CmdLabelAddspring::create_text, CmdIMDCopyUnitCell::create_text, CmdIMDRate::create_text, CmdIMDSim::create_text, CmdIMDConnect::create_text, CmdDisplayLightMove::create_text, CmdDisplayLightRot::create_text, CmdDisplayLightHL::create_text, CmdDisplayLightOn::create_text, CmdDisplayStageSize::create_text, CmdDisplayStagePanels::create_text, CmdDisplayStageLocation::create_text, CmdDisplayAxes::create_text, CmdDisplayAODirect::create_text, CmdDisplayAOAmbient::create_text, CmdDisplayAOOn::create_text, CmdDisplayShadowOn::create_text, CmdDisplayCueDensity::create_text, CmdDisplayCueEnd::create_text, CmdDisplayCueStart::create_text, CmdDisplayCueMode::create_text, CmdDisplayClip::create_text, CmdDisplayFPSOn::create_text, CmdDisplayBackgroundGradientOn::create_text, CmdDisplayCullingOn::create_text, CmdDisplayDepthcueOn::create_text, CmdDisplayAAOn::create_text, CmdDisplayScreenDistance::create_text, CmdDisplayScreenHeight::create_text, CmdDisplayFocallen::create_text, CmdDisplayEyesep::create_text, CmdDisplayProj::create_text, CmdDisplayRenderMode::create_text, CmdDisplayCacheMode::create_text, CmdDisplayStereoSwap::create_text, CmdDisplayStereo::create_text, CmdResetView::create_text, CmdColorScaleColors::create_text, CmdColorItem::create_text, CmdColorScaleSettings::create_text, CmdColorScaleMethod::create_text, CmdColorChange::create_text, CmdColorName::create_text, CmdAnimDup::create_text, CmdAnimDelete::create_text, CmdAnimWriteFile::create_text, CmdAnimSpeed::create_text, CmdAnimSkip::create_text, CmdAnimJump::create_text, CmdAnimStyle::create_text, and CmdAnimDir::create_text.

---

The documentation for this class was generated from the following file:

• Command.h

---
